300W Grid Tie Inverter Pure Sine Wave MPPT DC26-46V to AC110V for 36V PV Panel
Specifications
| Return Shipping Will Be Paid By | Seller |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 14 Days |
| AC Output Voltage | 110V AC |
| Application | Home/Garden |
| Brand | Y&H |
| Color | Silver |
| Country/Region Of Manufacture | China |
| DC Input | 18V-50V |
| Frequency Range | 50/60HZ Auto |
| Inverter Technology | Microinverter |
| Model | Pure Sine Wave Inverter |
| MPN | Does not apply |
| MPPT Voltage Range | 24V-40V |
| Power Source | Solar |
| Solar Panel Voltage | Vmp30-39V; Voc38-46V |
| System Configuration | Grid-Tie |
| Type | Solar Panel Kit |
| Voltage | 110 V |
| Wattage | 300W |
300W Grid Tie Inverter Pure Sine Wave MPPT DC26-46V to AC110V for 36V PV PanelGrid Tie Inverter MPPT Range 24-40VVmp(of a solar panel) must be in the MPPT range to ensure the good output efficiencyRecommended Solar Panel Voltage: Vmp30-39V; Voc38-46VSolar panel power cannot exceed 300WMicro Grid Tie Inverter Doesnt work with battery300W Grid Tie inverter is a compact unit,which directly converts direct current into alternating current for powering appliances and/or office equipments and connecting to utility grid.The AC output from Smart Micro inverter is synchronized and in-phase with the utility grid.Specification:Model: GMI 300Input Data(DC,PV)Number of Input MC4 Connector: 1 setMPPT Voltage Range: 24V-40VOperation Voltage Range: 18V-50VMaximum Input Voltage: 50VStartup Voltage: 18VMaximum Input Power: 300WMaximum Input Current: 12AOutput Data(AC)Single-Phase Grid Type: 120V Rated Output Power: 280WMaximum Output Power: 300WRated Output Current: 120V: 2.33ARated Output Voltage: 120V AC Default Output Voltage Range: @120V AC: 80V-160V Rated Output Frequency: 50Hz / 60HzDefault Output Frequency Range: @50Hz: 47.5Hz-52.5Hz / @60Hz: 57.5Hz-62.5HzPower Factor: >0.99Total Harmonic Distortion: THD <5%EfficiencyPeak Efficiency: 92.5%CEC Weighted Efficiency: @120VAC: 90.5% Nominal MPPT Efficiency: 99.9%Night Power Consumption: <700mWMechanical DataOperating Ambient Temperature Range: -40℃ to +65℃Storage Temperature Range: -40℃ to +85℃ Dimensions (W x H x D): 35x 76 x 233mmWeight: 0.5kgWaterproof Grade: IP55Cooling Mode: natural convection-no fansOther FeaturesTransformer Design: high frequency transformers, galvanically isolatedIntegrated Ground: equipment ground is provided by the PE in the AC cable. No additional ground is requiredProtection Functions: isolated island, voltage, frequency, temperature, current etc.User notice：• Use solar panel ONLY connect to this equipment.• This equipment is ON-GRID Microinverter, To make it work properly, it must be connected to the power grid correctly,and the power grid is working properly, When the power grid stopped working, it will also stop generating.• Do NOT exceed PV panel(s) voltage over the inverter max input voltage.（Voc＜50V）• Do NOT exceed PV panel(s) power over the inverter max input power.（300W）• The positive and negative poles of the solar panel cannot be reversed. If you extend the solar panel cable. You need to be careful about this problem.• Install away from direct sunlight and direct rain exposure.(Ventilated, dry, cool)About voltage：The 18-50V grid tie micro inverter will start up at 24V, after starting, the inverter can work in 18V-39V (Vmp).Solar Panel Voc cannot be higher than 50V.Vmp = solar panel working voltage; Voc = solar panel open circuit voltage.So don’t think that 50V is the working voltage (Vmp)Why not use 12V solar panels? 12V panel working voltage Vmp18-20V, open circuit voltage Voc20-24V.the 12V panel is just a starting voltage. If the sunlight is weak, the working voltage will be lower than 18V. It is easy to make the inverter work unstable, and the inverter will start repeatedly. It is easy to damage the inverter.Recommended Solar Panel Voltage: Vmp30-39V; Voc38-46VPackage Include:1 x Grid Tie Inverter1 x AC Cable 30CM1 x English Users ManaulShipping Policy:1. Items are usually shipped 1-3 business days after payment has been received.We do not ship on weekends and holidays.2.Sellers are not responsible for service transit time. Transit times are provided by the carrier, exclude weekends and holidays, and may vary with package origin and destination, particularly during peak periods.3. Delivery time depends on destination and other factors, it may takes up to 20 days. If you dont receive the item after 30 days, please contact us, well investigate and solve the delivery problem.4.International buyers are responsible for duties and customs fees.We are not responsible for any customs duties or import taxes (if any).5.Buyer from remote area should pay 35 USD more for the remote delivery service.(Only for Business Express ).Payment Method:1. Payment methods accepted : Paypal only.2. All major credit cards are accepted through our secure payment processor PayPal.3. Payment must be received within 4 business days of auction closing.4. We only ship to the confirmed address provided by ebay. Before you pay, please make sure your address in ebay matches the address you would like us to ship to.Returns Policy:1.One Year Warranty. Buy with confidence!2. Refund or replacement request is available only requests within a week after parcel received & returning the item as the same condition as received.Please include your eBay ID and brief description of defective problem in your return package.3. Defective situation must be noticed within 7 days after delivery.4. Buyer must pay the return postage for any return reason.In return,we will pay the shipping fee for send it back to you.5.Replacement or refund will be issued after the items are recevied by us in good condition.Feedback:1.We maintain all excellence 5 star DSR and strive for 100% customer satisfaction! Feedback is very important to us. 2.Please do not give us any bad feedback. Or contact us before you open a case. If you can do as we say, we will be very grateful.Please give us the opportunity to resolve any problem.Duties:1.Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyers responsibility. Please check with your countrys customs office to determine what these additional costs will be prior to bidding/buying.2.These charges are normally collected by the delivering freight (shipping) company or when you pick the item up, do not confuse them for additional shipping charges.3.Custom holds and delays vary from country to country and are beyond the control of the seller. Please do not hold us responsible for delivery delays caused by customs related issues. Thank You!WARRANTY:Our Y&H store products support a 2-year warranty period. Please contact us as soon as possible if you encounter any problems.If any problems occur within the one-year warranty period, we will provide after-sales accessories for free.If it exceeds one year, we still provide after-sales service, but the after-sales accessories need to be paid by yourself.Please rest assured to buy and enjoy our service.RETURNS:We support a free return policy within 30 days. If you encounter any problems, please contact us through eBay messages as soon as possible and inform us in detail the reason for your return request. We will reply to your message within 24 hours.You have requested a return and we will provide you with a free return.Once the returned items arrive at our warehouse and are evaluated, your refund will be processed.
